Tripp Lite by Eaton 14-Outlet Economy Network Server Surge Protector, 15 ft. (4.57 m) Cord, 3000 Joules, 1U Rack-Mount

  • Part: 1514236
$127.00

Availability

In Stock
  • General Information
    • Manufacturer
    • Tripp Lite by Eaton
    • Manufacturer Website Address
    • https://tripplite.eaton.com/
    • Brand Name
    • Tripp Lite by Eaton
    • Product Type
    • Surge Suppressor/Protector

Tripp Lite's DRS-1215 offers surge and noise suppression in a versatile all-metal multi-mount cabinet. Detachable mounting flanges are configurable for rackmount, wallmount and under-counter installation. Uses only 1 rack space (1U) when installed in any 19 inch EIA standard rack. Includes 14 outlets (6 front/8 rear), 15-ft. (4.57 m) AC power cord and guarded power switch to reduce the risk of accidental shutoff. Diagnostic LED indicates surge protection status.

PLUG/OUTLETS: Input: NEMA 5-15P/Output: 14 NEMA5-15R (6 front & 8 rear)

ELECTRICAL: 120V AC, 50/60Hz, 15A (Requires NEMA 5-15R wall receptacle)

SUPPRESSION: AC: 140V RMS Clamping/3000 joules

FORMAT: Supports 19 in. rackmount (uses 1 rack space/1U), wallmount, under-counter and more

Features

  • Versatile all-metal cabinet with detachable mounting flanges allows rackmount, wallmount, undercounter and other creative mounting options
  • Uses one rack space (1U) in standard 19 inch rack ("zero U" mounting possible in many racks)
  • 3000 joules AC surge suppression with EMI/RFI filtering
  • 14 NEMA 5-15R output receptacles (6 front/8 rear)
  • 15-ft. (4.57 m) AC cord with NEMA 5-15P straight-in plug connection
  • Diagnostic LED confirms suppressor operation
  • Lighted power switch confirms power on/off status
  • Snap-in switch guard prevents accidental turn off
  • 15 amp capacity with circuit breaker
  • 120V AC, 50/60Hz electrical compatibility

More from the Manufacturer

  • Warranty
    • Limited Warranty
    • Lifetime

  • Technical Information
    • Plug/Connector Type
    • NEMA 5-15P
    • Receptacles
    • 14 x NEMA 5-15R
    • Protection Type
    • Surge
  • Power Description
    • Input Voltage
    • 120 V AC
    • Output Voltage
    • 120 V AC
    • Maximum Line Current
    • 15 A
    • Power Handling
    • 1800 VA
    • Surge Energy Rating
    • 3000 J
    • Circuit Breaker
    • Yes
  • Physical Characteristics
    • Color Family
    • Black
    • Product Color
    • Black
    • Product Material
    • Metal
    • Power Cord/Cable Length
    • 15 ft
    • Form Factor
    • Rack-mountable
    • Height
    • 1.8"
    • Width
    • 17.5"
    • Depth
    • 4"
    • Weight (Approximate)
    • 4.60 lb
  • Miscellaneous
    • Package Contents
      • DRS-1215 14 Outlets 120V Surge Suppressor
      • Warranty information
      • Instruction manual
    • Additional Information
      • Snap-in switch guard prevents accidental turn off
    • Compatibility
      • Ideal for protection of sensitive electronic equipment in 19 inch rackmount, wallmount and under-counter applications, such as internetworking equipment, PC systems, telecommunications, audio/video, security and sound reinforcement
    • Certifications & Standards
      • UL1449 (Let through rating 330V)
      • cUL
      • IEEE 587 category A and B specifications
    • Country of Origin
    • China
    • Environmentally Friendly
    • Yes
    • Environmental Compliance
    • Restriction of Hazardous Substances (RoHS)
