- General Information
- Manufacturer
- Sophos Plc
- Manufacturer Website Address
- http://www.sophos.com
- Brand Name
- Sophos
- Product Type
- Wireless Access Point
- Technical Information
- Wireless LAN Standard
- IEEE 802.11ac
- ISM Band
- Yes
- UNII Band
- Yes
- ISM Minimum Frequency
- 2.41 GHz
- ISM Maximum Frequency
- 2.47 GHz
- UNII Minimum Frequency
- 5.18 GHz
- UNII Maximum Frequency
- 5.83 GHz
- Number of External Antennas
- 3
- Antenna Gain (Isotropic)
- 2 dBi
- Antenna Type
- Dipole Antenna
- Antenna Connector
- RP-SMA Connector
- Wireless Transmission Speed
- 1.27 Gbit/s
- Wireless Security
- WPA
- WPA2
- WEP
- IEEE 802.1x (RADIUS)
- Features
- Security Slot
- Interfaces/Ports
- Ethernet Technology
- Ethernet
- Fast Ethernet
- Gigabit Ethernet
- Number of Network (RJ-45) Ports
- 1
- Network (RJ-11)
- No
- PoE (RJ-45) Port
- No
- VGA
- No
- HDMI
- No
- Audio Line Out
- No
- USB
- Yes
- Powerline
- No
- Management Port
- Yes
- Power Description
- Input Voltage
- 12 V DC
- Physical Characteristics
- Form Factor
- Wall Mountable
- Desktop
- Height
- 1.4"
- Width
- 7.2"
- Depth
- 7.2"
- Weight (Approximate)
- 1.11 lb
- Miscellaneous
- Certifications & Standards
- CE
- FCC
- Radio: EN 300 328, EN 301 893 CFR 47, Part 15 Subpart C, E
- EMC: EN 301 489-1, EN 301 489-17 CFR 47, Part 15 Subpart B
- EMF: EN 50385 FCC 1.1310, IEEE C95.1
- Safety: EN 60950-1
- 802.3
- 802.3u
- 802.3ab
- 802.11a
- 802.11b
- 802.11g
- 802.11n
- 802.11ac
- 802.3af
- 802.3at
