The digital transformation: Converged wired and wireless access and aggregation
The promise of digital for your business is all about innovating more quickly while reducing risk, cost, and complexity. It will be your network that forms the foundation of your business's transformation.
But supporting your digital organization will require your network to move beyond just connectivity to be a platform for insights, automation, and security.
- General Information
- Manufacturer
- Cisco Systems, Inc
- Manufacturer Website Address
- http://www.cisco.com
- Brand Name
- Cisco
- Product Line
- Catalyst
- Product Series
- 3850
- Product Type
- Layer 3 Switch
- Warranty
- Limited Warranty
- Lifetime
- Technical Information
- Features
- Plug and Play
- Energy Efficient
- High Availability Supported
- Yes
- Interfaces/Ports
- Total Number of Network Ports
- 48
- Uplink Port
- Yes
- Stack Port
- Yes
- Network (RJ-45)
- Yes
- Port/Expansion Slot Details
- 48 x 10/100/1000BASE-T Gigabit Ethernet PoE+ RJ-45 Network Port
- 1 x Management Port
- Media & Performance
- Media Type Supported
- Twisted Pair
- Ethernet Technology
- Gigabit Ethernet
- Network Technology
- 10/100/1000Base-T
- Maximum Data Transfer Rate
- 125 MB/s
- Network & Communication
- Layer Supported
- 3
- Networking Standards
- IEEE 802.1as
- IEEE 802.1s
- IEEE 802.1w
- IEEE 802.1x
- IEEE 802.3ad
- IEEE802.3af
- IEEE 802.3at
- IEEE 802.3bz
- IEEE 802.1D
- IEEE 802.1p
- IEEE 802.1Qat
- IEEE 802.1Qav
- IEEE 802.1Q
- IEEE 802.3
- IEEE 802.3u
- IEEE 802.3ab
- IEEE 802.3z
- Management & Protocols
- Manageable
- Yes
- Reliability
- MTBF
- 241050 Hour
- Power Description
- PoE (RJ-45) Port
- Yes
- PoE Budget
- 800 W
- Input Voltage
- 120 V AC
- 230 V AC
- Frequency
- 50 Hz
- 60 Hz
- Power Source
- Power Supply
- PoE+
- Redundant Power Supply Supported
- Yes
- Number of Power Supplies Supported
- 2
- Number of Power Supplies Installed
- 2
- Power Consumption
- 129.18 W
- Plug/Connector Type
- IEC 320-C16
- Physical Characteristics
- Compatible Rack Unit
- 1U
- Form Factor
- Rack-mountable
- Desktop
- Height
- 1.8"
- Width
- 17.5"
- Depth
- 19.2"
- Weight (Approximate)
- 17.60 lb
- Miscellaneous
- Application/Usage
- Business
- Network
- Wireless Access Point
- IP Phone
- Campus
- Branch Office
- Enterprise
- Certifications & Standards
Safety certifications
- UL 60950-1 Second Edition
- CAN/CSA-C22.2 No. 60950-1 Second Edition
- EN 60950-1 Second Edition
- IEC 60950-1 Second Edition
- NOM (obtained by partners and distributors)
Electromagnetic emissions certifications
- 47CFR Part 15 (CFR 47) Class A (FCC Part 15 Class A)
- AS/NZS CISPR22 Class A
- CISPR22 Class A
- EN55022 Class A
- ICES003 Class A
- VCCI Class A
- EN61000-3-2
- EN61000-3-3
- KN22 Class A
- KCC
- CNS13438 Class A
- EN55024
- CISPR24
- KN24
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS) 5
